Manual Batch Distillation Pilot Plant

Manual Batch Distillation Pilot Plant
Product Name: Manual Batch Distillation Pilot Plant
Product Code: CHM0003

Description and Specification for Lab Tenders

Manual Batch Distillation Pilot Plant.

Manual Batch Distillation Pilot Plant Lab Equipments Manufacturer, Suppliers & Exporters

Manual Batch Distillation Pilot Plant

  •     Distillation column height 600 mm with 7 bubble cap trays.
  •     Re-boiler with 4 liters capacity complete with 1600 W electric heater.
  •     Condenser with reflux head.
  •     Tank for collection of distillate with 1 liter capacity.
  •     Tube in tube heat exchangers manufactured from AISI 304 stainless steel
  •     6 thermocouples with  probes protected by stainless steel shield sleeves
  •     6 electronic temperature indicators
  •     Pneumatic valve for controlling the condenser cooling water made of stainless steel
  •     Residual pressure electronic transmitter made of stainless steel with a range of 0-1000 mbar and 4-20mA output signal.
  •     Pneumatic valve for controlling the residual pressure made of stainless steel
  •     Residual pressure electronic transmitter made of stainless steel with a range of 0-1000 mbar and 4-20mA output signal.
  •     Pneumatic valve for controlling the residual pressure made of stainless steel
  •     2x electropneumatic converters 0.2 to 1.0 bar and 4-20mA signals
  •     Thyristor unit for controlling the power to the re-boiler electric heater.
  •     2x programmable timers for the control of reflux ratio
  •     Variable-area flow meter made of stainless steel with a  range 20 to 250 liters / hour and 4-20mA output signal
  •     Oil vacuum pump with trap and flow rate of 4m3/hour
  •     Vacuum gauge range 0 to –1 bar
  •     Electrical control panel in main cabinet
  •     Vacuum circuit with trap
  •     Pipe work and valves manufactured from stainless steel.
  •     Microprocessor digital PID controller with serial card.
